Image Sensor

1 MP CMOS image sensor

Signal System

PAL/NTSC

Effective Pixels

1296 (H) × 732 (V)

Min. illumination

0.01 Lux@(F1.2, AGC ON), 0 Lux with IR

Shutter Time

1/25 (1/30) s to 1/50,000 s

Lens

2.8 mm, 3.6 mm, 6 mm optional

Field of view: 70.9°(3.6 mm), 92°(2.8 mm), 56.7°(6 mm)

Lens Mount

M12

Day & Night

ICR

Angle Adjustment

Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°

Synchronization

Internal synchronization

Video Frame Rate

720 p@25fps/720p@30fps

HD Video Output

1 analog HD output

S/N Ratio

> 62 dB

General

O perating Conditions

-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)

Power Supply

12 V DC ± 15%

Power Consumption

Max. 4 W

IR Range

Up to 20 m

Dimensions

Φ 89.9 mm × 70.1 mm (3.54" × 2.76")

Weight

250 g (0.55 lb.)
